Stok Kodu : 240-127

Digital Discovery with High Speed Adapter Bundle

10.500,00 TL
Barkod
240-127
Fiyat
250,00 USD + KDV
Digilent Son Kullanıcı Bilgi Formu
*

Digital Discovery with High Speed Adapter Bundle

P/N:240-127

The Digilent Digital Discovery™ is a combined logic analyzer and pattern generator instrument that was created to be the ultimate embedded development companion. Digital Discovery was designed to optimize channels, speed, and portability. A small form factor facilitates easy storage and provides a whole suite of advanced features to allow you to debug, visualize, and simulate digital signals for most embedded projects. Digital inputs and outputs can be connected to a circuit using simple wire probes or breadboard wires; alternatively, the Digital Discovery High Speed Adapter and impedance-matched probes can be used to connect and utilize the inputs and outputs for more advanced projects.
The High Speed Adapter, for the 32-pin connector on the Digital Discovery, is an alternative to the 2X16 flywire assembly. It provides access for up to 24 High Speed Logic Probes and allows increased sample rates for up 800 MS/s on the Digital Discovery. The adapter is not keyed, and both orientations can be used as the twisted wires are not color-coded.


Features

  • 32-channel digital logic analyzer (1.2…3.3V CMOS, 8 channels at 800MS/s*, 16 channels at 400MS/s*, and 32 channels at 200MS/s)
    • Digital Bus Analyzers (SPI, I²C, UART, CAN, Parallel)
  • 16-channel pattern generator (1.2…3.3V CMOS, 100MS/s)
  • 16-channel virtual digital I/O including buttons, switches, and LEDs – perfect for logic training applications
  • A programmable power supply of 1.2…3.3V/100mA. The same voltage supplies the Logic Analyzer input buffers and the Pattern Generator input/output buffers, for keeping the logic level compatibility with the circuit under test.
  • High Speed Adapter provides increased sample rates of up to 800 MS/s on the Digital Discovery
  • Ships with 16 High Speed logic Probes
  • Free WaveForms Software Application
