Stok Kodu : UTD2102CL+
Unit UTD2102CL+ 100Mhz Dijital Osiloskop
12.417,96 TL
Unit UTD2102CL+ 100Mhz Dijital Osiloskop
Math function
- Support addition, subtraction, multiplication, division, and waveform calculation functions.
ZOOM function
- You can observe the overall situation and details of the waveform.
XY mode (also called Lissajous graphics mode)
- Can measure the phase difference between two signals of the same frequency.
Brand new AUTO strategy
- The state after AUTO can be set
Standard square wave output
- With 10hz, 100hz, 1Khz, 10Khz local signal standard square wave output.
Automatic parameter measurement
- With 34 kinds of automatic parameter measurement, 5 groups of customizable parameter display
Grade Display
- Grade display can view the worst case of changing waveforms, capture rare and abnormal signals.
ZOOM function
- It can be effectively applied to trigger signals without frequency correlation.
